ZOK mx Heavy-Duty Gas Turbine Compressor Cleaner – 25 Litre

ZOK

ZOK mx is a concentrated, water-based, biodegradable gas turbine compressor and gas-path cleaner specifically formulated for heavy-duty cleaning requirements.

Its higher-pH formulation provides powerful cleaning performance for removing carbon, salt, oil, grease, atmospheric contamination, and other difficult deposits from compressor blades, Inlet Guide Vanes, and gas-path components.

ZOK mx is designed as an environmentally responsible alternative to conventional solvent-based cleaners. Regular online and offline compressor washing helps prevent long-term fouling, recover power output, improve fuel efficiency, reduce exhaust-gas temperatures and emissions, and extend the service life of gas turbine components.

Unlike ZOK 27, ZOK mx does not contain an added corrosion inhibitor. A water rinse and dry-out run are therefore recommended after cleaning, subject to the gas turbine manufacturer’s maintenance instructions.

ZOK mx is supplied as a concentrate and should be mixed at a ratio of one part product to four parts water, producing a 20% cleaning solution. Ready-to-use versions may also be available.

PERFORMANCE ADVANTAGES
• Heavy-duty gas turbine compressor cleaning
• Removes carbon, salt, oil, grease, and atmospheric contaminants
• Higher-pH formulation for challenging cleaning requirements
• Suitable for online and offline compressor washing
• Helps recover gas turbine power output
• Helps improve fuel efficiency
• Helps reduce exhaust-gas temperatures
• Helps reduce harmful emissions
• Helps extend component and equipment service life
• Reduces long-term compressor fouling
• Water-based and biodegradable
• Non-flammable formulation
• Alternative to conventional solvent cleaners
• Low ash content for hot-wash applications
• Suitable for aviation, industrial, offshore, and power-generation turbines

IMPORTANT PRODUCT DIFFERENCE
ZOK mx has a higher pH than ZOK 27 and is intended for more challenging or heavy-duty cleaning requirements.

ZOK mx does not contain an added corrosion inhibitor. A water rinse and dry-out run are recommended after use unless the equipment manufacturer provides different instructions.

COMPOSITION
A special blend of non-ionic surfactants, organic solvents, and demineralised water.

DILUTION AND DIRECTIONS
Mix one part ZOK mx concentrate with four parts water to produce a 20% cleaning solution.

For hot or online cleaning, use demineralised water with conductivity below 11 µS/cm.

For cold or offline cleaning, good-quality drinking water with conductivity below 500 µS/cm may be used.

Apply using a spray ring or lance during starter-driven offline washing or fired online washing. Follow the engine manufacturer’s maintenance manual for injection quantities and procedures.

A water rinse and dry-out run are recommended after cleaning. Antifreeze should be added when operating below +5°C, following the manufacturer’s recommended dilution.

Contact Sales
Specifications

• Product type: Heavy-duty gas turbine compressor cleaner
• Product form: Concentrated liquid
• Formulation: Water-based and biodegradable
• Appearance: Pale straw-coloured liquid
• Odour: Mild and pleasant
• Typical pH: 8.0–8.5
• Typical specific gravity: 1.00
• Corrosion inhibitor: No added corrosion inhibitor
• Standard dilution: 1 part product to 4 parts water
• Recommended working concentration: 20%
• Total alkali metals after dilution: Below 4 ppm
• Ash content: Below 0.01%
• Aromatic compounds: None
• Alkylphenol ethoxylates: None
• Hydrocarbon solvents: None
• 2-Butoxyethanol: None
• Shelf life: 5 years
• Water rinse after cleaning: Recommended
• Dry-out run after cleaning: Recommended
• Storage temperature: +4°C to +60°C
• Sales method: Request for quotation

Applications

• Online gas turbine compressor washing
• Offline gas turbine compressor washing
• Hot or fired compressor washing
• Cold or starter-driven compressor washing
• Compressor blade cleaning
• Inlet Guide Vane cleaning
• Gas-path cleaning
• Removal of carbon deposits
• Removal of salt, oil, and grease
• Removal of stubborn atmospheric contamination
• Preventive gas turbine maintenance

Industry Usage

• Aviation
• Marine
• Offshore installations
• Oil and gas
• Petrochemical facilities
• Industrial gas turbines
• Power generation
• Military and defence
• Gas turbine maintenance contractors
